Chauvet Professional NETXII Net-X II Ethernet to RDM/DMX Node 1U Rack-Mountable

Net-XII serves as a versatile rack-mountable Ethernet-to-DMX node and a merger for two controllers using Ethernet or DMX inputs. It can store up to 10 DMX presets for remote activation. With two 5-pin DMX inputs and eight 5-pin DMX outputs, all optically isolated, it can simultaneously output up to eight universes. These outputs can be individually assigned to any of the inputs, allowing for flexible configurations. Net-X II supports LTP and HTP merging for sACN, Art-Net, or DMX, and includes RDM over network functionality. It offers an easy preset setup for beginners and customizable network infrastructure for advanced users.

• Webserver supported for remote configuration and backup/update
• 5-pin DMX splitter/distributor
• DMX to Art-Net/sACN converter, up to 8 universes
• Art-Net/sACN to DMX converter, up to 8 universes
• Supports RDM over Art-Net for remote fixture management
• Integrated Record function allows you to record looks from a controller and save them into memory (10 shows in memory, 100 steps each) to trigger up to 4 shows/zones, 1 at a time, using the 5-wire Phoenix cold contacts on the rear of the unit
• Merge two 5-pin DMX universes into a single universe, or merge 2 NET controllers (Art-Net or sACN) into the same universe, then convert to standard 5-pin DMX for the outputs
• HTP (highest takes priority) and LTP (latest takes priority) merge functions supported
• Backup settings and configurations with same or other NET-X IIs
